Overview

Basic Info.

Model NO.	HQC23-240/1000/500-Y02
Number of Charging Interfaces	One Pile with Multiple Charges
Location	Public Use
Installation	Floor Type
Charge Method	Quick Charge
Rated Power	240kw
Input Voltage	AC380V±10%
Protection Level	IP55
Operation Temperature	-40°c~+60°c
Gun Cable Length	Car:4.5m Bus:6m
Communications Protocol	Ocpp1.6j
Connectivity	Ethernet/WiFi/4G
Cooling	Forced Air Cooling
LED	Three Color Indicator Light
Over/Under Voltage Protection	Yes
Over Temperature Protection	Yes
Surge Protection	Yes
Emergency Stop Button	Yes
Output Voltage	200-1000V DC
Charging Point	2*CCS2
Transport Package	Safety Wooden Box Packaging
Specification	800mm*1900mm*750mm
Trademark	HARDHITTER or Customized
Origin	Shandong, China
HS Code	8504409999
Production Capacity	3000 Pieces Per Year

Product Description

Product Description

Rated Power	240kW
Input Voltage	AC380V±10%
Output Voltage	200~1000V
Efficiency	≥95%(Load rate≥50%)
Start Mode	Swipe Card, Scan Code, Plug and Charge, Platform remote start, button Start
Protection Level	IP55
Operation Temperature	-40°C~+60°C
Altitude	≤2000m
Dimensions	W800mm*H1900mm*D750mm
Weight	289kg(Without modules)
Gun Cable Length	Car:4.5m Bus:6m
Cooling Method	Air Cooling
Communication Interface	Ethernet/4G
Wiring Method	Bottom Incoming
Interface	LED+digital tube display
Communication Protocol	hardhitter(proprietary protocol) OCPP1.6(2.0 optional)

--Adopting high-efficiency dustproof mesh, it can effectively filter dust, and the protection level can reach IP55. The power module adopts a fully glue-pouring process, with high protection level, high system reliability, and long system life; --Supports GB/T, CCS2, and CHAdeMO charging interfaces, and multiple standard charging interfaces can be freely combined; --Can be configured with a 7-inch true color touch screen, card reader, POS machine, etc., to meet various interaction methods; --Support multiple charging startup methods such as scanning code charging, swiping card charging, plug and play charging, button start charging, remote start charging, timed charging, etc; --Support dual gun charging for one vehicle at the same time, meeting the dual gun charging method for buses and heavy truck vehicles; --Adopting the front door maintenance method, it can be installed against the wall.

1. Q: How about your Lead time?A: Generally, it will takes 15 to 25 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
2. Q: Does your products have quality certification?
   A: We have a very strict quality controlling system which promises the goods we produced are always of the best quality. Our EV charging products passes with CE&TUV certifications.
3. Q: How long is the warranty?
   A: The warranty of our products is 12 months upon the receipt of your shipment under normal circumstances.
4. Q: What is your guarantee of after-sale service?A: In response to every single after-sale request within the warranty, we will appoint a one-on-one technician for timely online aid.
5. Q: Can you provide customized service?A: Yes. We have been getting involved with the OEM and ODM projects since 2012. So that we can provide professional customized service for our clients.
6. Q: What is your term of payment?A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
7. Q: Can the EV charger charge all Electric Vehicle on the road?A: Yes, all models of our EV Charger work with all Electric Vehicles. Tesla vehicles need the use of a J1772 to Tesla adapter to work with our EV chargers.
8. Q: Does the EV Charger need any APPs or internet?A: Some models are set be to standalone type which use RFID card to start or plug and play mode . Some models are Wi-Fi connected and can work with App and any OCPP 1.6j application. Details please feel free to ask.
